Quick Charge On-Board Select-A-Charge

SELECT-A-CHARGE

ON BOARD CHARGERS

NEW FEATURES FOR AN OLD STANDARD

Now you don't have to change chargers if you change battery types. The NEW ON BOARD Select-A-Charge line is the last charger you'll ever need. Switch from wet deep cycle, AGM, or starting batteries with the push of a button. Also selectable is the type of gassing/absorption mode. If set to shut off mode, baby sit feature recycles charger if voltage drops too low. Optional ambient temperature compensation is available for extreme temperatures. The digital readout shows percent of charge, and battery voltage, plus a tri color LED for a more informed charge cycle.

Scissor Lifts, Floor Scrubbers, Engine Standby Generators, Railroads, Pallet Jacks, Electric Vehicles, RV's, Oil field, Mining

#1 REPLACEMENT CHARGER, FITS ANYWHERE

Small And Compact:

Fits Slim Scissors, mounts in any direction

Vibration Resistant:

No moving parts, and an integral design

Rugged Construction:

Totally enclosed to resist the effects of water, dirt, and a harsh environment. Pressure washer proof

Near bullet proof:

Tough die cast enclosure

Made in U.S.A.

Selectable Charge Profiles:

F1 - Float: Regulates the battery voltage at 2.3 volts per cell. Best for starting batteries, and gel's This charger provides a continuous preset voltage determined by the model you buy.

F2 - Gas & timed shut off: Timer trips at 2.3vpc, gassing threshold. Batteries are allowed to gas to a maximum of 2.55vpc before shut off. Best for deep cycle batteries This charger provides a one time charge per plug in cycle. Plug, charge, then go.

F3 - Gas & float: Timer trips at 2.3vpc, gassing threshold. Batteries are allowed to gas to a maximum of 2.55vpc before dropping into indefinite float of 2.26vpc. Best for deep cycle batteries that may see long periods of inactivity. This charger provides a one time charge then a float charge.

F4 - AGM: Batteries bulk charge to 2.3vpc, and enter absorption cycle where voltage is allowed to climb to a maximum 2.45vpc before dropping into indefinite float of 2.26vpc. This charger provides a one time charge then float charge. For AGM batteries.

Other volt/amp combinations available upon request.

Model	DC VOLTS	DC AMPS	AC POWER	Dimensions H.D.W. in.	WEIGHT	BATTERY CAPACITY @ 20 Hr.rate	COST	BUY
SCO1225	12	25	117v 60hz. 3 amps	6 x 9 x 5.5	18	150-350 Amp Hour	$282 plus $14.95 shipping
SCO1235	12	35	117v 60hz. 5 amps	6 x 9 x 8.5	27	220-450 Amp Hour	$345 plus $17.95 shipping
SCO1250	12	50	117v 60hz. 8 amps	6 x 9 x 9	36	350-550 Amp Hour	$410 plus $19.95 shipping
SCO2425	24	25	117v 60hz. 6 amps	6 x 9 x 6.5	26	150-350 Amp Hour	$339 plus $17.95 shipping
SCO2440	24	40	117v 60hz. 10 amps	6 x 9 x 9	36	220-450 Amp Hour	$410 plus $19.95 shipping
SCO3225	32	25	117v 60hz. 9 amps	6 x 9 x 7	34	150-350 Amp Hour	$367 plus $19.95 shipping
SCO3625	36	25	117v 60hz. 9 amps	6 x 9 x 7	34	150-350 Amp Hour	$390 plus $19.95 shipping
SCO3635	36	35	117v 60hz. 12 amps	6 x 9 x 9	43	220-450 Amp Hour	$466 plus $21.95 shipping
SCO4815	48	15	117v 60hz. 6 amps	6 x 9 x 6.5	26	100-225 Amp Hour	$339 plus $17.95 shipping
SCO4825	48	25	117v 60hz. 12 amps	6 x 9 x 8	42	150-350 Amp Hour	$445 plus $21.95 shipping
SCO6420	64	20	117v 60hz. 14 amps	6 x 9 x 8	42	1150-300 Amp Hour	$445 plus $21.95 shipping
SCO7210	72	10	117v 60hz. 7 amps	6 x 9 x 6.5	26	80-150 Amp Hour	$383 plus $17.95 shipping
SCO7220	72	20	117v 60hz. 14 amps	6 x 9 x 8	42	150-300 Amp Hour	$445 plus $21.95 shipping
SCO8413	84	13	117v 60hz. 12 amps	6 x 9 x 8	42	80-150 Amp Hour	$445 plus $21.95 shipping
SCO9612	96	12	117v 60hz. 12amps	6 x 9 x 8	42	80-150 Amp Hour	$445 plus $21.95 shipping
SCO12010	120	10	117v 60hz. 12 amps	6 x 9 x 8	42	80-150 Amp Hour	$455 plus $21.95 shipping

All models available in 230 v 50 Hz. as Models SCOXU for $15 more
